Brugsanvisning SilverCrest IAN 66402 Koblingsur

Brugsanvisning

GB GB GB GB

GB GB GB GB

GB GB GB GB

Product description:

Digital Timer

Art. No.: 97317-3

ModelNo.: EIM-803DK

Disposal

The packaging is wholly composed of environ-

mentally friendly materials that can be disposed

of at a local recycling centre.

Contact your local refuse disposal authority for more details

of how to dispose of your discarded product.

In the interest of the environment, do not throw

out your discarded device with your household

refuse. Take it to a suitable centre where it can

be disposed of properly. Your local council will

be able to tell you where the collection centres

are located and their opening times.

Setting the button lock

Note: This function locks the buttons so that the programmed

settings cannot be unintentionally changed.

Press the time button

3

until the symbol appears in

the LC display

2

.

Note: The button lock has no effect on the stored

switching times.

Note: If the symbol flashes in the LC display

2

, all

the subsequent switching times will be skipped (refer to

the section on “Skipping switching times”).

Cleaning and care

Never use liquids or cleaning agents, as they may

damage the device.

Clean the outside of the device only with a soft, dry

cloth.

Programming

No switching

time

Daylight / brightness Switch state

19:00 hrs / light (approx. 500 lux) Off

19:30 hrs / dark (approx. 5 lux) On

00:00 hrs / dark (approx. 0 lux) On

06:00 hrs / dark (approx. 20 lux) On

08:00 hrs / twilight (approx. 50 lux) Off

12:00 hrs / light (approx. 500 lux) Off

Programming

On 20:00hrs /

Off 23:55hrs

Daylight / brightness Switch state

19:00 hrs / light (approx. 500 lux) Off

20:00 hrs / light (approx. 500 lux) On

22:00 hrs / dark (approx. 0 lux) On

23:30 hrs / dark (approx. 0 lux) On

23:55 hrs / dark (approx. 0 lux) Off

02:00 hrs / dark (approx. 5 lux) Off

Examples of twilight sensor function:

Programming

On 20:00hrs /

Off 23:55hrs

Daylight / brightness Switch state

19:00 hrs / light (approx. 500 lux) Off

19:30 hrs / dark (approx. 5 lux) On

20:30 hrs / dark (approx. 0 lux) On

23:30 hrs / dark (approx. 0 lux) On

23:55 hrs / dark (approx. 0 lux) Off

02:00 hrs / dark (approx. 5 lux) Off

Note: The 15-second delay prevents the device from auto-

matically switching in response to a short period of shadow

or light. The indicators ON and OFF flash alternately in the

LC display

2

during this delay.

Manually ending the countdown

Press the ON / OFF button

5

to halt the countdown.

Press the ON / OFF button

5

again to continue the

countdown.

Press the time button

3

to change from the countdown

display to the current time.

Press the time button

3

again to change from the

current time to the countdown display.

Press the time button

3

and the ON / OFF button

5

simultaneously to cancel the countdown.

Twilight sensor

This function orients the time switch’s switching times to

dawn and dusk twilight. The programmed switching times

are automatically adjusted to the light conditions. The time

switch automatically switches on or off as soon as the twilight

sensor

1

detects a change of light conditions lasting for

more than 15 seconds. This function is only active at dawn

or dusk. It does not affect operation during the day or night.

Press the day of the week button (Day)

6

and the hour

button (h+)

8

again to cancel the random mode.

Setting the countdown

Press the timer button

4

to access the timer menu.

Press and keep pressed the timer button

4

until the

“

ON

C” symbol appears in the LC display

2

.

Press the ON / OFF button

5

to switch the countdown

function on and off.

Press the hour button (h+)

8

repeatedly until the desired

hour value appears in the LC display

2

.

Press the minute button (m+)

7

repeatedly until the

desired minute value appears in the LC display

2

.

Press the timer button

3

to store the setting. The

current time appears again.

Press the time button

3

and the ON / OFF button

5

simultaneously to start the countdown.

Note: The countdown can be set from 1 minute to

99 hours, 59 minutes.

ON: All switching times are cancelled and the attached

consumer is permanently switched on.

Press ON / OFF switch

5

for about 5 seconds. The

switching times and twilight sensor are activated again.

The indicator “A” appears in the LC display

2

.

Setting the random mode

Note: This function switches the time switch arbitrarily on

and off. This is intended to prevent burglaries by simulating

an occupied house with e.g. lights switching on and off at

irregular intervals. Your preprogrammed switching commands

are moved by a random amount up to 30 minutes on each

day. This function is only possible if one or more switching

commands have been set.

Press the day of the week button (Day)

6

and hour

button (h+)

8

simultaneously. The symbol “Timer”

flashes in the LC display

2

and the random mode is

switched on.

Cancelling switching times

Press the timer button

4

. The programmed switching

times appear in the display.

Press the ON / OFF button

5

to cancel the selected

programmed switching time. The symbol “H I : d E”

appears in the LC display

2

.

Press the ON / OFF switch

5

for longer than 5 seconds

to cancel the switching time. The “- - : - -” symbol appears

in the LC display

2

.

Switching the time switch manually

At any time, and independently of programmed times,

you can manually skip a subsequent switching time.

To do this, press the ON / OFF button

5

until the

symbol “A” disappears from the time indicator.

Press the ON / OFF button

5

once to choose between

the following options:

OFF: All switching times are cancelled and the attached

consumer is permanently switched off.

Changing or checking switching

times

To change or check the switching times, press the timer

button

4

and the programmed switching times appear

one after the other in the display.

To change the days, hours or minutes, proceed as described

in the section “Entering switching times”.

Skipping switching times

Press the timer button

4

. The programmed switching

times appear one after the other in the display.

Press the ON / OFF button

5

to cancel the selected

programmed switching times. The symbol “H I : d E”

appears in the LC display

2

.

Press the time button

3

to return to normal operating

mode.

Note: The programmed switching times are not deleted

from the memory and can be reactivated by pressing the

ON / OFF button

5

again.

© by ORFGEN Marketing

IAN 66401

Inter-Union Technohandel GmbH

Klaus-von-Klitzing-Str. 2

D-76829 Landau / Pfalz

66402_Zeitschaltuhr_Daemmerungssensor_DK.indd 3 02.08.11 09:14
