Brugsanvisning Hoover CAN1700R 011 Damprenser

Brugsanvisning

2

GETTING TO KNOW YOUR CLEANER

A. Steam Release Trigger *

B. Handle Assembly

B1a. Steam Boost Button*

B1b. Variable Steam Release Control Slider Maximum, Medium & Low *

C. Upper & Lower Cord Storage Hooks

D. Power Cord

E. Metal Tube

F. Cleaner Main Body

G. Handle Release Button

H. Cleaner Carry Handle

I. Clean Water Tank Release Latch

J. Clean Water Tank

K. Hard Water Filter

L. Power On /Off Button

M. Power On Indicator Light ( Metallic Red )

N. Steam Ready Light ( Green )

O. Handle Storage Location

P. Floor Head**

P1a. Triangular Brush*

P1b. Triangular Brush Release Pedal *

Q. Textile Pads

R. Carpet Glider

S. Glider release pedal

ASSEMBLING YOUR CLEANER

Remove all components from the packaging.

1. Insert the Handle Assembly pole into the Cleaner Main body until it locks into

position. [1]

2. Assemble the main body of the cleaner to the Triangular Brush. [2]

3. Assemble the main body of the cleaner to the oor Head and assemble the Triangular

Brush into the Floor Head.* [3]

USING YOUR CLEANER

BEFORE YOU BEGIN CLEANING

1. Release the clean water tank by sliding the water release button upwards and

remove tank from cleaner main body. [5]

2. Twist the cap anti clockwise and remove. [6]

3. Fill the clean water tank with cold tap water. Replace cap. [7] Do not

add any chemicals, detergents or perfumes to the clean water tank.

4. Re-t the clean water tank to the cleaner ensuring the hard water lter is in place.

5. Attach a textile pad to the base of the oor Head. [8]

IMPORTANT: Always unplug the cleaner when adding water or changing

a textile pad.

NOTE: Wash the textile pad prior to use to remove any lint.

STEAM CLEANING HARD FLOORS

NOTE: Always sweep or vacuum the oor prior to use to remove any loose

dirt or debris.

IMPORTANT: Do not use the cleaner without a textile pad attached to the

oor head.

NOTE: Do not use the carpet glider when cleaning hard oors.

1. Plug the steam cleaner into the main power. The red ON light will illuminate.

2. After a few seconds the green Steam Ready light will

illuminate indicating the cleaner is ready for use.

3. Recline the cleaner by placing a foot on the oor head and

lowering the main body towards the oor. [9]

4. To produce steam press the Steam Trigger Button. [10]*

5. Move the cleaner slowly backwards and forwards paying

particular attention to high trafc areas. [12]

6. For certain models to produce steam , just select your cleaning setting on

the Slider control located on the handle. Minimum, Medium or Maximum

depending on your specic cleaning requirement and recline the cleaner. [11]*

7. On Certain model the cleaner is equipped with a steam boost button

located on the Handle. This allow the user to apply extra cleaning

power for 10 seconds to help remove stubborn marks. [11]*

Steam cleaning hard oor - intensive clean

Use the triangular oor brush for hard oors that require deep cleaning. Please note that

there is no mop and the area will have to be dried separately.

NOTE: Always sweep or vacuum the oor prior to use to remove any loose dirt or debris.

1. Remove the triangular oor brush from the oor head by pressing the release pedal

at the rear of the oor head. [13]

2. Plug the steam cleaner into the main power. The red ON light will illuminate. After

a few seconds the green Steam Ready light will illuminate indicating the cleaner is

ready for use.

3. Recline the cleaner by placing a foot on the oor brush and lowering the main body

towards the oor. [14]

4. To produce steam press the trigger release button. [10]*

5. For certain models to produce steam, just select your cleaning setting on the

Slider control located on the handle. Minimum, Medium or Maximum depending

on your specic cleaning requirement and recline the cleaner. [11]*

6. On Certain model the cleaner is equipped with a steam boost button

located on the Handle. This allow the user to apply extra cleaning

power for 10 second to help remove stubborn marks. [11]*

*Certain Models Only **Nozzle design may vary according to models
