Brugsanvisning Denver DAB-18LW Radio

Brugsanvisning

ENG 3

ENG 4

LOCATION OF CONTROLS

1 2 3 4 5 6 7 8 9 10

1.

Volume knob

2.

Speakers

3.

Standby

4.

Scan button

5.

Preset button

6.

LCD display

7.

Info button

8.

Alarm set button

9.

DAB/FM/AUX/BLUETOOTH

10.

Tune/Select knob

11.

Antenna

12.

Battery compartment

13.

AUX in jack

14.

DC jack

Remove old or discharged batteries from the product. Remove the batteries when the product will not

be used for extended periods of time to prevent damage due to rusted or corroded batteries.

Never throw batteries into a fire, do not expose batteries to fire or other heat sources.

Battery Disposal: Old or discharged batteries must be properly disposed of and recycled in compliance

with all applicable laws. For detailed information, contact your local solid waste authority.

Follow the battery manufacturer’s safety, usage, and disposal instructions.

OPERATION

Press the Power button to turn the unit on.

IN DAB MODE

Press the DAB/FM/AUX/BT button to select DAB radio mode

Auto select : Press the SCAN button, “SCANNING” will show on the display, and the number of DAB

station will shown on the upper right corner, and it will automatically play the first station. Tune and

press the TUNE/SELECT knob to choose the next or previous station.

Manual select: Press and hold the INFO button and tune the “TUNE/SELECT” knob until the “MANUAL

TUNE” icon shown on the display, then tune the TUNE/SELECT knob to choose the station.

Note: you many have to wait for the unit to tune in to the new channel.

11 12 13 14

OWER SUPPLY

OPERATING THE UNIT ON AC POWER

Insert one end at the supplied power cord to the DC 5V IN Jack located at the rear of the unit and the

other end into the Wall outlet.

When the First time used the cord has to be firmly pushed into the socket if does not work on AC, to

try again to be sure for a positive connection.

OPERATING THE UNIT ON BATTERIES

To play your unit on batteries, the AC power cord must be disconnected from the player.

Unplug the AC power cord from the unit and insert 4 size “C” batteries (not provided) in the compartment.

Close the battery compartment door.

Note:

Ch eck your batteries regularly. Old or discharged batteries should be replaced. If the unit is not

to be used for sometime or is being run exclusively on AC electrical current, remove batteries from the

battery compartment to avoid leakage.

Warning: Before using the unit. Check that the local mains supply is compatible with the Unit Do not

plug or unplug the power cable when your hands wet.

When planning not to use this unit for long periods of time (i.e. Vacation etc.) disconnect the plug from

the wall outlet.

BATTERY SAFETY PRECAUTIONS:

Keep batteries away from children and pets.

Insert the batteries observing the proper polarity (+/-). Failure to properly align the battery polarity can

cause personal injury and/or property damage.

DAB Radio stations presetting:

To receive the desired DAB station, press and hold the PRESET button, “Preset Store” “<1: (Empty)>

will appear on the display,

Tune the TUNE/SELECT knob to choose your desired program number (1-10) you want stored to.

Then press TUNE/SELECT knob to store it.

Repeat the same procedures until all the desired radio stations were stored into the program list.

Recall the memory, press PRESET button and tune the TUNE/SELECT knob to select the stored radio

station as desired. Press the TUNE/SELECT knob toconfirm.

IN FM MODE

Press the DAB/FM/AUX/BT button to select FM radio mode, press the SCAN button, when a radio is

found, the frequency on display will stop running and start playback automatically.

If reception is no good, tune the TUNE/SELECT knob to fine tune. FM radio presetting is same as DAB

radio presetting

INFO Button

A. The UNIT has DAB information modes which are shown on the bottom line of the display. Long

press the INFO key and tune “TUNE/SELECT” knob to see the available types, press “INFO” to

turn back.

1. Full Scan

Full scan the DAB radio channels

2. Manual Scan

Scan the DAB radio channels manually

3. Dynamic range compression (DRC) (Off/ High/ Low)

This function reduces the difference between the loudest and quietest audio being broadcast.

Effectively, this makes quiet sounds comparatively louder, and loud sounds comparatively quieter.
