08/2018_V 1.1
Trademarks
USB is a registered trademark.
Other names and products may be the trademarks or
registered trademarks of their respective owners.
Introduction
Thank you for purchasing a SilverCrest product. The SilverCrest
triple socket car charger adapter enables you to operate
several devices with a car charger adapter in your vehicle. You
can also connect a USB device to the integrated USB charge
socket (4). You can use the joint connector (2) to adjust the
triple socket car charger adapter up to approx. 90° according
to your needs.
Intended use
This triple socket car charger adapter is not designed for
commercial use or operation in a company, but solely for
private purposes in cars, caravans or camping vehicles with
12V / 24V vehicle equipment. Any other use is not as
intended.
This triple socket car charger adapter meets all relevant norms
and standards in conjunction with CE conformity. In the event
of any modification to the triple socket car charger adapter
that was not approved by the manufacturer, compliance with
these standards is no longer guaranteed. The manufacturer
does not accept any liability for any resulting damage or faults
in such cases.
Please observe the regulations and laws in the country of use.
Supplied items
1. SilverCrest SLM 4 B1 triple socket car charger adapter
2. These operating instructions (symbolic representation)
Technical data
Input voltage 12V / 24V (DC voltage)
Output voltage 3 x 12V / 24V (DC
voltage)
USB output voltage 5V / 2,1A
Operating temperature -10 °C to +45 °C
Air humidity max. 85 % rel. air humidity
Fuse 10A 32V
Hinged joint connector (2) 0° - 22.5° - 45° - 67.5° -
90°
Dimensions (W x H x D)
without joint connector (2)
approx. 12.3 x 5.0 x 3.4cm
Weight approx. 110 g
The technical data and design may be changed without
notification.
Safety instructions
Before using the triple socket car charger adapter for the first
time, please read the following instructions carefully even if you
are familiar with using electronic devices. Store these operating
instructions in a safe place for future reference. If you pass on
the triple socket car charger adapter to someone else, be sure
to always include these operating instructions. They are an
integral part of the device.
DANGER! This symbol indicates an imminent
dangerous situation which, if not prevented, could
result in serious injury or even death.
WARNING! This symbol indicates important
information for safe operation of the device and
the safety of the user.
This symbol indicates other important information
on the topic.
Operating environment
The triple socket car charger adapter may be used only within
a vehicle, and must not be used outdoors. It is not designed for
use in environments with a high temperature or humidity, and
must be kept free from dust. Operating temperatures and
operating air humidity: -10 °C to +45 °C, max. 85 % rel. air
humidity.
DANGER! Ensure that
no direct heat sources (e.g. heating) can affect the triple
socket car charger adapter because it may be damaged
otherwise.
the triple socket car charger adapter is not exposed to direct
sunlight or bright artificial light because it may be damaged
otherwise.
no fire sources (e.g. burning candles) are placed on or near
the triple socket car charger adapter because there is a risk
of fire.
no foreign objects penetrate the device because there is a
risk of a short circuit.
contact with sprayed and dripping water and corrosive
liquids is prevented and the triple socket car charger adapter
is never operated near water; in particular, it should never
be immersed (do not place any objects filled with liquids
such as vases or drinks on or near the triple socket car
charger adapter as there is a risk of fire or a short circuit).
the triple socket car charger adapter is not exposed to
extreme temperature fluctuations as this could result in
condensation and electrical short circuits and there is a risk
of fire. If the device was subjected to extreme temperature
fluctuations, however, wait (approx. 2 hours) until the device
has reached ambient temperature before use.
DANGER! Children and persons
with disabilities
Electrical devices do not belong in the hands of children.
Persons with disabilities should also only use electrical devices
appropriately. Never allow children or persons with disabilities
to use electrical devices unsupervised. They may not recognise
potential risks. Small parts can be fatal if swallowed. Always
keep plastic packaging out of reach also. It poses a
suffocation risk.
Overview
1 LED operating indicator (white)
2
oint connector
3 Car power outlet 12V / 24V
4 USB charge socket
5Fuse cover
