10
English
Our products are engineered to meet the
highest standards of quality, functionality
and design. We hope you thoroughly
enjoy your new Braun appliance.
Please read the use instruc tions
carefully before first use.
Important
•
This appliance shall not be used
by children. Keep the appliance
and its cord out of reach of
children. Switch off the appliance
and disconnect from supply
before changing accessories or
approaching parts that move in
use.
•
This appliance can be used by
persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given super-
vision or instruction concerning
use of the appliance in a safe way
and if they understand the
hazards involved.
•
The blade
9
is very
sharp! Take hold of the
blady by the knob only. After use,
always first remove the blade
from the food processor bowl
6
before removing the processed
food.
•
Make sure that your voltage
corre sponds to the voltage
printed on the bottom of the
appliance. Connect to alternating
current only.
•
Keep the appliance out of the
reach of children.
•
This appliance was constructed
for household use only to process
the listed quantities.
•
Do not use any parts in the micro-
wave oven.
•
Do not allow the appliance to
operate unsupervised.
•
Braun electric appliances meet
applicable safety standards.
Repairs or the replacement of the
mains cord must only be done by
authorised service personnel.
Faulty, unqualified repair work
may cause considerable hazards
to the user.
•
Always disconnect the appliance
from the supply if it is left unat-
tended and before assembling,
disassembling or cleaning.
Specifications
• Voltage/wattage: See typeplate on the
bottom of the appliance.
• Operating time and max. capacity:
See processing instructions.
Description
The Braun food processor FP 3010 /
FP 3020 meets highest demands for
kneading, mixing, blending, chopping,
slicing, shredding and grating, both
simply and quickly.
1 Motor block
2 Cord storage
3 Motor switch (on = «I», off = «O»)
4 Pulse mode «»
5 Variable speed regulator (1 - 15)
6 Food processor bowl (2 l capacity)
7 Lid for food processor bowl 6
8 Pusher for lid 7
Attachments for food processor
bowl 6
(Important: Not all attachments will be
included in the standard equipment of
all models.)
9 Blade with protective cover
j Insert carrier
q Fine slicing insert – a
l Coarse slicing insert – b
m Fine shredding insert – c
n Coarse shredding insert – d
o Grating insert – e
p French-fries system
q Kneading hook
r Whipping attachment
s Citrus press
t Chopper attachment
Note: Before using the food processor
for the first time, clean all parts as
described under «Cleaning».
Overload protection
In order to avoid damages caused by
overload, this appliance is equipped with
an automatic security switch which shuts
off the current supply if necessary. In
such case, turn the motor switch 3 back
to «O» and wait approx. 15 minutes to
allow the motor to cool off before switch-
ing on the appliance again.
Pulse mode «» 4
The pulse mode is for example useful
for the following applications:
• Chopping delicate and soft food, e.g.,
eggs, onions or parsley.
• Carefully folding flour into dough or
batter to maintain the creaminess.
• Adding whipped eggs or cream to
more solid food.
The pulse mode «» is activated by
turning the motor switch to the left.
The switch does not catch at this
setting. Hold the switch in pulse
position or turn it to pulse position
repeatedly.
Before activating the pulse mode, set
the desired speed with the speed regu-
lator 5. When releasing the pulse mode,
the appliance is switched off.
Recommended speed
ranges for individual attach-
ments
Set the speed range by means of the
variable speed regulator 5. It is recom-
mended to first select the speed and
then switch on the appliance in order to
work whith the desired speed right from
the beginning.
Attachments Speed range
Kneading hook 7
Blade 6 - 15
Whipping attachment:
– egg-whites 4 - 5
– cream 2
Slicing, grating and
shredding inserts 1 - 8
French-fries system 1 - 2
(please also refer to product printing)
Double safety feature
The appliance can only be switched on
when the food processor bowl with lid is
properly engaged. If the lid is opened
during operation, the motor switches off
automatically. As in this case the motor
switch 3 is still on «I», turn it back to
«O» to avoid switching on the motor
accidentally.
Attaching the food processor
bowl 6 and the lid 7
1. With the motor switched off, place
the food processor bowl onto the drive
place of the motor block 1 matching
the arrow on the bowl with the arrow on
the motor block (A). Then turn the bowl
in the «function» direction as far as it
will go.
2. Put the attachment needed (see
instructions for each of the attachments)
onto the drive shaft of the bowl and
push it down as far as it will go.
3. Put the lid 7 onto the bowl matching
the arrow on the lid with the arrow on
the bowl.
Then turn the lid clockwise guiding its
nose rim into the safety lock opening of
A
1
2
